Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research

Tianjia New Material Technology (Hubei) Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research

Brand Name : Tianjia

Model Number : Single person single blow

Certification : CE,ISO

Place of Origin : wuhan, China

MOQ : 1Pcs

Price : $3500.00/sets 1-4 sets $3000.00/sets 5 sets

Payment Terms : T/T, L/C

Supply Ability : 100 Set/Sets per Month

Packaging Details : Wooden Case, Galvanized Steel Pallet, Plastic Film

Port : Shanghai/Wuhan

Installation Method : Modular or Stick-built

Color : White, Grey, Blue, Green

Interior Steel Thickness : 0.4mm-0.6mm

Thickness : 50/100/175mm

Surface : Steel, Stainless, PVC

Structure : Assembled

Fire Resistance : Class A or Class B

Material Depth : 1.0mm PCGI

Application : Workshop, Building

Advantage : Easy Install,High filtration efficiency,Semi-sterile

Marketing Type : New Product 2025

shape : Square

Filtration Efficiency : ≥0.3um Dust>99.95%

Nozzle Speed : ≥20m/Sec

Air Volume : ≥3000m³/H

Weight : 250kg

Maximum Power : 1.5kw

High Efficiency Filter Specifications : 820*600*50

Fluorescent Lamp Specifications : 12W

Box Structure : Steel Plate Spraying/Color Steel Plate/304 Stain

Chassis : High Quality SUS304 Stainless Steel Channel

Contact Now

HEPA Filter Included 304 Stainless Steel Cleanroom Air Shower


Product Features:

1. Humanized control panel design, clear indicator light indication, and clear air shower flow indication. Soft key touch type time relay;
2. High cleanliness and wind speed: two-stage filtration system with primary and high efficiency filters is adopted, no partition plate with low resistance and high efficiency filters. The filtration efficiency is 99.99% to ensure the clean level. Equipped with all stainless steel multi-angle adjustable nozzle, double volute outer rotor large air volume and low noise fan, the air outlet wind speed of the air nozzle is as high as more than 25 m/s, and the wind speed is more than 18 m/s when blowing on people.
3. Modular structure. The air shower box adopts a modular design scheme, which can be assembled into various lengths of air shower sizes according to actual demand. One air shower is composed of one or multiple air shower units. For large-volume air shower equipment, it can be divided into multiple modules which making production, transportation and installation particularly convenient and fast;
4. High performance and high sealing: Qualified electronic components, stable and reliable operation performance, advanced noise reduction and mute device system with EVA high sealing material.

Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research

Applications:
1. Automatic control. The single-person single-blowing air shower system adopts PLC intelligent control means. The LED display screen on the control panel can correctly display the running state of air shower, the interlocking state of double doors, the progress of air shower cycle and the delayed opening state. It is also equipped with a photoelectric sensor and a one-way channel air shower room, which enters from the non-clean area. After closing the door, the infrared ray senses the person to blow the shower. After blowing the shower, the entrance is locked and the air shower room can only be walked out of the air shower room from the door;
2. Single-person single-blown air shower main board soft key touch time relay, LED display and set blowing time, adjustable in the range of 10-99s, which can adjust the blowing time according to the difference of the external environment of the air shower room;
3. Modular structure, single-person single-blowing shower chamber box adopts modular design solution.

Advantages:

1. Improved Cleanliness: By removing contaminants from personnel and objects, it significantly reduces the risk of contamination in the cleanroom, improving the overall cleanliness level.
2. Enhanced Product Quality: Helps to ensure the quality and reliability of products manufactured in cleanroom environments, especially in industries where precision and purity are crucial.
3. Cost-Effective: Compared to other contamination control measures, air showers offer a cost-effective solution for maintaining cleanroom standards.
4. Increased Efficiency: The quick and efficient decontamination process enables smooth workflow and reduces downtime.
5. Compliance with Standards: Helps facilities comply with strict industry standards and regulations regarding cleanliness and contamination control.


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research
Packaging and Transportation:

Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research



Specification:

Exterior Size
W1400*D1000*H2250
W1400*D1500*H2250
W1400*D2000*H2250
InternalSize
W900*D900*H2100
W900*D1400*H2150
W900*D1900*H2150
Filter Efficiency
≥99.99%(@≥0.3μm)
Air Velocity
≥20 m/s(4920fpm)
Showering Time
0~99 s (Adjustable)
Num.of Nozzle
12
18
24
Power Supply
AC380V, 3Φ, 50Hz
Body
High grade steel with ivory color static powder coating
Floor
Stainless steel bottom plate
Door
Aluminum alloy with tempered glass



Certifications


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research




Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research


Stainless Steel Air Shower Local Purification Equipment For Blowing And Dust Removal For Food Electronics Medicine And Scientific Research
